Semi-Hermetic Piston Compressor Unit (U-Type Top Discharge, 9–12HP)

Post a comment
5.00
In stock
+
  • View all variations as list
Description

This high-capacity U-Type semi-hermetic piston compressor unit is built for large cold rooms and low-temperature freezer systems. With robust components and advanced heat exchange efficiency, it ensures long-lasting performance and consistent temperature control in demanding refrigeration environments. The top discharge design with a single high-power fan makes it suitable for installations where vertical airflow is preferred or required.

Key Features:

  • Semi-Hermetic Piston Compressor for industrial-grade cooling performance

  • Single 630 mm fan with powerful 1000W motor for efficient airflow

  • Evaporation temperature range: -40°C to -10°C

  • Ambient temperature compatibility: -25°C to +48°C

  • Refrigerants supported: R404A, R448A, R507A, R452A

  • Large condenser area: 95/162/143 m² for optimal heat dissipation

  • Integrated oil separator, gas-liquid separator, and 16L liquid receiver

  • Compact for its capacity: Dimensions: 1700×770×1140 mm

  • Net weight: 270 kg

  • Sound level at 1m: 70 dB

Features
Brand:
Dashang

Dimensions

Dimensions:
1700×770×1140 mm

Condensing Units

Product Type:
Semi-Hermetic Units
Unit Capacity:
9 HP
Compressor Type:
Piston
Application:
  • Freezer
  • Cold Room
Air Discharge Direction:
Top Blowing
Cooling Method:
Air-Cooled
Number of Fans:
1
