Engineered for large-capacity industrial refrigeration systems, this V-Type top discharge unit features a multi-fan configuration and a powerful semi-hermetic piston compressor. Designed to ensure reliable cooling for expansive cold rooms and freezing tunnels, it delivers exceptional thermal performance and system protection, even under intense operating conditions.
Key Features:
-
Semi-Hermetic Piston Compressor with advanced internal cooling and protection
-
Multi-fan system for optimal airflow distribution across large condenser surfaces
-
Refrigeration capacity range: 20–40HP, adaptable for high-load environments
-
Evaporation temperature range: -40°C to -10°C
-
Ambient temperature tolerance: -25°C to +48°C
-
Refrigerants supported: R404A, R448A, R507A, R452A
-
Heat exchange area: 200–500 m²
-
Fan diameter: 630 mm; each powered by 1100W x2 motors (per module)
-
Integrated oil separator, gas-liquid separator, and a large-capacity 29L liquid receiver
-
Equipped with high/low pressure gauge, Schneider/CHiNT electrical components, and LCD/relay-based control board
-
Operating noise: 69 dB @ 1m
-
Unit weight: 750 kg
-
Dimensions: 2400×1000×2350 mm
Dimensions
